Chemical Composition
|
Chemical |
Fe |
C |
Si |
Mn |
S |
|
Spec (%) |
99.60Min. |
0.01Max. |
0.1Max. |
0.25Max. |
0.01Max. |
|
Chemical |
p |
Al |
Cu |
Ni |
Cr |
|
Spec (%) |
0.015Max. |
0.01Max. |
0.01Max. |
0.01Max. |
0.01Max |
⚡ Core Advantages Table
| Feature | Xinye Taiming Advantage | Industry Standard |
|---|---|---|
| Purity Level | 99.99% electrolytic iron (Fe ≥99.99%) | 99.8% commercial purity |
| Magnetic Permeability | 5,000 μH/m (DC-10kHz) | 3,500 μH/m |
| Surface Finish | Mirror-polished (Ra ≤0.2μm) | Ra ≤1.6μm |
| Corrosion Resistance | ASTM B117 salt spray >500hrs (Ni-Cu coated option) | ≤72hrs uncoated |
| Customization | 12+ diameters (0.1mm–5.0mm), annealing options | Limited sizes |
🧪 Material Composition & Properties (Table Format)
| Component | Grade/Process | Key Properties | Application Impact |
|---|---|---|---|
| Iron Core | ASTM A848 Grade 1 | 99.99% purity, ≤50ppm impurities | Enhanced signal accuracy in sensors |
| Trace Elements | C ≤0.003%, S ≤0.002% | Ultra-low carbon content | Reduced magnetic aging |
| Surface Treatment | Electroless nickel plating (Optional) | 5-20μm thickness | Corrosion resistance in harsh environments |
| Annealing Process | Hydrogen atmosphere annealing | HRB 45–50 hardness | Optimized ductility for winding/stamping |
📊 Mechanical & Magnetic Performance (Table Format)
| Parameter | XT-PI25 (0.25mm) | XT-PI50 (0.5mm) | XT-PI100 (1.0mm) |
|---|---|---|---|
| Tensile Strength | 380–420 MPa | 350–390 MPa | 320–360 MPa |
| Elongation | ≥25% | ≥28% | ≥30% |
| Coercivity (Hc) | ≤80 A/m | ≤75 A/m | ≤70 A/m |
| Resistivity | 0.12 μΩ·m | 0.11 μΩ·m | 0.10 μΩ·m |
| Max Operating Temp | 180°C (Coated) | 180°C (Coated) | 180°C (Coated) |
🛠️ Application-Specific Recommendations
| Sensor Type | Critical Requirements | Ideal XT Model | Performance Benefit |
|---|---|---|---|
| Automotive Position Sensors | High linearity, vibration resistance | XT-PI50 (Ni-coated) | ±0.5% linearity @-40°C–150°C |
| Medical Flow Sensors | Biocompatibility, micro-diameter | XT-PI25 (Medical-grade) | FDA-compliant surface finish |
| Industrial Pressure Sensors | Fatigue resistance, high permeability | XT-PI100 (Annealed) | 10^7 cycle durability @50N load |
| IoT Magnetic Switches | Low coercivity, rapid response | XT-PI25 (Ultra-soft) | 5ms response time @3V |
✅ Quality Control & Certifications
| Test Criteria | Standard Method | Xinye Taiming Spec |
|---|---|---|
| Dimensional Tolerance | ISO 286-2 | ±0.5μm (≤1mm dia) / ±1μm (>1mm) |
| Magnetic Hysteresis | IEC 60404-4 | ≤1.5T residual magnetism |
| Microstructure Analysis | ASTM E3/E112 | Grain size 7-8 (ASTM scale) |
| RoHS Compliance | EN 62321 | Full adherence (Cd/Pb/Cr-free) |
❓ Technical FAQ (Table Format)
| Question | Expert Guidance |
|---|---|
| How does purity affect sensor sensitivity? | 99.99% Fe reduces eddy current loss by 40% vs. standard grades, improving signal-to-noise ratio |
| Lead time for custom diameters? | 10–15 days for orders ≥500kg (laser-calibrated drawing) |
| MOQ for specialty coatings? | 200kg minimum (e.g., Au/Pt plating for medical use) |
| Packaging options? | Vacuum-sealed spools (5kg–20kg) or straight rods (1m/2m lengths) |
Package
Pure iron is typically packaged with rust-preventive oil, wrapped in plastic film, and secured with plastic or metal straps. It is then placed on wooden pallets or in wooden crates, sometimes using moisture-proof paper or vacuum packaging for extra protection during transportation and storage.
